Everything you need to know about the 8.5×20 Tandem

from any of our top 2 manufacturers plus our helpful maintenance guide

Table of Content - 8.5x20 Tandem Axle

1. Technical Comparison Table

→ → →

Standard Features Diamond Anvil
PRICE $7,600.00 $7,100.00
EXTERIOR METAL .080 Polycore Exterior (Semi-screwed) .080 Polycore Exterior (Semi-screwed)
AXLES 3500lb USA Made Lippert Drop Leaf Spring Axles 3500lb USA Made Drop Leaf Spring Axle
V-NOSE  V Nose (Standard) V Nose (Standard)
ELECTRIC BRAKES  Axles w/ Electric Brakes Axles w/ Electric Brakes
DOME LIGHT (2x) 12V LED Dome Light with switch 12V Dome light with switch
WALLS/CEILING TUBING  1.5" x 1" steel tube in walls and ceiling 1.5" x 1" steel tube in walls and ceiling
FLOOR TUBING  6" steel tube main frame 6" steel tube main rails
FLOOR CROSS-MEMBERS Floor Members 16" O.C. Floor Members 16" O.C.
ROOF CROSS-MEMBERS Roof Members 16" O.C. Roof Members 24" O.C.
WALL CROSS-MEMBERS Wall Members 16" O.C. Wall Members 16" O.C.
LIGHTS  All LED exterior lighting incl. Rear Loading Light All LED exterior lighting
INTERIOR HEIGHT 7' (84") Interior Height 6'6" (78") Interior Height
REAR DOOR Heavy Duty Ramp Door w/ Spring Assist & 16" Extension Flap / Door Hold Back / (2) Rear Door Handles Ramp Door w/ Spring Assist & Extension Flap
PLUG / COUPLER (BALL) 7-way Round Bargman Plug / 2 5 / 16" Coupler 7-way round plug/ 2 5 / 16" coupler
FENDERS Aluminum fenders w/lights Aluminum fenders w/lights
SIDE DOOR 36" RV-Style Side Door w/ Flush Lock 36" RV-Style Side Door w/ Flush Lock & Hold Open
ATP ATP In Stepwell  / ATP Front & Rear Corners ATP In Stepwell  / ATP Front & Rear Corners
TIRES ST205 15" Radial Tires ST205 15" Radial Tires
RIMS/WHEELS Silver Painted Wheels Silver Painted Wheels
ROOF MATERIAL  Galvalume roof Galvalume roof
STONEGUARD 24" Stoneguard on front 24" Stoneguard on front
TONGUE JACK 5000 lb A-Frame tongue jack w/ Sand Foot 2000 lb tongue jack w/ Sand Foot
HUBS  EZ Lube Hubs EZ Lube Hubs
THERMA-PLY Therma-Ply Ceiling ❌​
WALL MATERIAL Premium 3/8" plywood sidewalls Premium 3/8" plywood sidewalls
FLOOR MATERIAL 3/4" plywood floor/undercoated 3/4" plywood floor/undercoated
SIDEWALL VENTS Plastic Sidewall Vents Plastic Side Vents
DRINGS (4) 5000lb D-Rings Welded to Frame 4 Floor D-rings
BEAVERTAIL No Show Beavertail Beavertail frame
EMPTY WEIGHT 3200 lbs 3200 lbs
LOAD CAPACITY 3800 lbs 3800 lbs
GVWR 7000 lbs 7000 lbs
TONGUE WEIGHT 480 lbs 480 lbs

2. Technical FAQ

Overall Length: 23'6" / 282 in (Breakdown: 20' on the Box + 3'6" on the Tongue) 20" on the Vnose
Overall Width: 8’6"/ 102 in (Breakdown: 8’6" on the Box)
Overall Height ( Diamond ): 8'4" / 100 in (Breakdown: 7' on the Box + 16"from the ground to the box)
Overall Height (Anvil): 7'10" / 94 in (Breakdown: 6'6" on the Box + 16"from the ground to the box)

Overall Length: 19'9" Box (Breakdown: Subtract 3" which counts for rear door & framing) plus 20" on the Vnose
Overall Width: 8' Wall to Wall (Breakdown: Subtract 3" (each wall) which counts for framing & Plywood)
Width Between Wheel Boxes: 81 inches (Breakdown: Subtract 7.5" (each side) which counts for wheel boxes
Overall Height ( Diamond ): 7'
Overall Height (Anvil): 6'6"

Width: 90" (Breakdown: Subtract 12" (6 on each side) which counts for plywood & framing)
Height ( Diamond ): 78" (Breakdown: Subtract 6" which counts for plywood & framing)
Height (Anvil): 72" (Breakdown: Subtract 6" which counts for plywood & framing)

7-way Round plug

5×4.5 (5 Lug)

6 Ply

Screws are 4' apart instead of being every 2'

It's an asphalt undercoating paint

We developed a section exclusively for Custom Options where we show sample photos and explain most popular options:

Click Here for More Information.

Here are examples of some of the most popular Custom Options:

– Blackout Package
– Electrical Package
– Insulation Package
– Rubber Flooring
– Etracks
– D-rings
– Windows
– Extended Tongue
– Extra Height
– Ladder Racks
– Finished Interior (Metal/Vinyl)
– Air Conditioner
– Lighting Options
– Axle Upgrades
– Concession Window
– Special Door Options
– Cabinets
– Barn Doors

3. Sample Photos

4. Sample Video

5. Sample Colors (click to enlarge)

6. Purchase FAQ

We work our financing arrangements through our third party business partner, below is their information:



Rock Solid Funding
https://www.rocksolidfunding.com/

Phone: 800-607-1108



NOTE: We recommend creating a quote before calling the financing company.

We work our delivery service arrangements through our third party business partners, below is their information:

TJ’s Transport: (912) 389-1965
Loyd’s Transport: (912) 381-2138










30 Day Temporary Tag, Certificate of Origin and obviously your Title so you can register your brand new trailer

Yes they are and also the reason why your trailer pick up is directly at the Factory

We do not charge any taxes, that's something that you pay when you register the trailer

Yes, as soon as your trailer is ready we can provide your with your VIN number.



1) Credit or Debit Card (over the phone or invoice sent to your email)
2) Mail a Cashier's Check
3) Wire Transfer

Once your deposit is confirmed we’ll send you an email just make everything official and after 24 hours (timeframe we provide in case of any changes) we will send your order to our production team so they can start working on your future top notch trailer

It depends on 2 factors: The season and your Order so make sure to ask our awesome sales team for a more accurate completion timeframe but on average you might be looking between 2 to 4 weeks on standard order and about 3 to 5 weeks for orders with custom options.



Note: We do make exceptions so make sure to ask our sales team

We don’t usually provide any updates during the building process but we can definitely ask our production team how things are going but as soon as your trailer is ready, we will send you the completion email along with the instructions so you can start your pick up arrangements

7. Create a Quote

8. Still Got Questions?

We try to cover all the basic questions so our customers can make an informed and smart purchase, but if we missed any information that prevents you from moving forward please feel free to email, chat or call us, our awesome and knowledgeable sales team will be happy to help.

9. Ready to Purchase

Please enable JavaScript in your browser to complete this form.
Do you have an invoice number?

Please enable JavaScript in your browser to complete this form.
Do you have an invoice number?

Please enable JavaScript in your browser to complete this form.
Do you have an invoice number?

Have you recently invested in an enclosed cargo trailer, or are you looking to maximize the lifespan and efficiency of your current one? Our comprehensive PDF guide is your ultimate companion to mastering the art of trailer maintenance!

Safeguard Your Investment:

10 Smart Ways to Prevent Trailer Theft!

Useful Article About:

8.5x20 Enclosed Trailers by MakeMyTrailer.com, Built to Last!

8.5x20 enclosed trailers

Introduction: The Demand for Quality in 8.5×20 enclosed trailers

The search for the perfect 8.5×20 enclosed trailer is driven by a diverse group of buyers, each looking for a spacious and secure solution for their transportation needs. This size has become highly sought after for its balance of space and manageability of your car hauler and xtreme cargo.

8.5x 20 enclosed trailer

Global Choices, Local Decisions for cargo trailer options

With a vast array of 8.5×20 enclosed trailers available globally, buyers are spoilt for choice. The internet has opened up a world where comparing models and prices is easier than ever, leading many to this model for its exceptional offerings.

Special Prices, Special Opportunities for 8.5x 20 enclosed trailer charcoal options

The market occasionally offers special pricing on these trailers, providing a unique opportunity for buyers to secure premium features at a reduced cost. Such deals are not to be missed for those seeking value. it is essential to consider certain things such as axle type, side door, lb capacity, plywood, blackout, vent, interior height, ramp door, charcoal, iti cargo, semi-screwless exterior, corever wagon trailers 8.5×20, blackout package, v nose, rv door, d-rings, white blackout, factory direct, utv, leds, flap, lb axles, extra height, escape door, car trailer, torsion axles, e-z, heavy duty build, plywood floors, coupler, stoneguard, ladder racks, and much more.

The Quest for the Ideal 8.5 x 20 enclosed trailer

Finding the right 8.5×20 enclosed trailer involves weighing options for features against personal or business needs. Whether seeking simplicity or a feature-rich model, the choice significantly impacts utility and satisfaction.

8.5 x 20 enclosed trailer

The Price-Quality Equation for the 8.5×20 enclosed trailer for sale

The search term “8.5×20 enclosed trailer for sale” reveals a competitive market where price correlates with quality. Buyers are encouraged to explore various vendors and read extensive customer reviews to gauge the best value proposition. Keep in mind that payments are estimates in most cases and fees are extra. Make sure that you read the provacy policy for any dealer in order to get the best options that fit your needs in 2023 and 2024.

The Value of Research for the cargo trailer black and charcoal gray 8.5×24 or 8.5×20

Informed decisions stem from thorough research. Potential buyers are advised to delve into the specifics of each trailer, comparing prices and features to determine if the investment is justified by the trailer’s offerings. You can consider models like the covered wagon trailers 8.5×20, 8.5×20 tandem axle, 8.5×24 enclosed, cargo 8.5×20, trailer 7000, 030, 030 exterior, 030 aluminum, plywood walls, charcoal gray, usa cargo trailer, stud, cargo trailer black, s 6’6, stealth trailers 8.5×20, slant v-nose, 3500, and the 5200 amongst many others.

8.5x20 enclosed trailer for sale

Ensuring Trailer Excellence for the 8.5 x20 enclosed trailer for sale

Quality assurance is crucial when purchasing an 8.5×20 enclosed trailer. Inspecting trailers closely or opting for new models can ensure that the purchase meets expectations for quality and longevity.

A World of Trailer Variety with the xtreme cargo and white blackout enclosed cargo trailer options

From stacker trailers to gooseneck models, the variety of enclosed trailers available caters to every possible need, highlighting the importance of identifying specific requirements before making a purchase.

Scouting for Used Trailer Deals in v nose and ladder racks or extra height

While rare, exceptional deals on used 8.5×20 enclosed trailers do exist. Patience and persistent searching can uncover offers that provide significant savings without compromising on quality.

Leveraging Online Resources for an 8.5 x 20 enclosed trailer for sale near me

The internet is a treasure trove of information, offering insights, reviews, and comparisons to aid in the trailer buying process. Utilizing these resources can simplify the search and lead to satisfying purchases. Please enter your contact information and one of our representatives will provide information you need based on the current inventory for the xtreme cargo trailer for sale.

8.5 x20 enclosed trailer for sale

The Popularity of the 8.5×20 car trailer lb capacity for usa cargo trailer and related products

The 8.5×20 enclosed trailer is favored for its ample space, making it a top choice for those needing to haul large items or quantities, evidenced by its widespread acclaim among buyers of the 8.5 by 20 enclosed trailer. The features include 7k capacity and duty ramp amongst others for the 8.5×18 enclosed as well.

Investing in an Enclosed Car Hauler and considering torsion axles for 8.5×20

For vehicle transportation, the 8.5×20 enclosed car hauler presents a secure and reliable option, proving to be a wise investment for both individuals and businesses.

The Appeal of the V-Nose Trailer and 8.5×20 black

Opting for an 8.5×20 v-nose enclosed trailer offers aerodynamic benefits and potentially more usable space, making it a preferred choice for efficiency-conscious buyers of the 8.5 20 enclosed trailer.

8.5 x 20 enclosed trailer for sale near me

Finding the Best Deals on trailer 7000

Though challenging, locating a super deal on high-quality 8.5×20 trailers is possible with dedicated research and timing, underscoring the value of a proactive search strategy for the 8.5×20 enclosed trailer dimensions.

The Rich Variety of Trailer Models and heavy duty 5200

The availability of diverse models like enclosed living quarter trailers and car haulers ensures that there’s a perfect trailer for every need, showcasing the versatility and value of the 8.5×20 enclosed trailer.

Making the Optimal Purchase for the 8.5×20 enclosed trailer

Securing the best 8.5×20 enclosed cargo trailer is about more than just finding a good deal; it’s about ensuring the trailer fits your specific needs and budget, making every dollar spent a step towards achieving your goals.

Final Thoughts on factory direct

Finding the right 8.5×20 enclosed trailer is a journey that requires attention to detail, patience, and thorough research. By carefully considering your needs, exploring the market, and taking advantage of available resources, you can make a purchase that not only meets but exceeds your expectations. Whether for personal use, business, or recreation, the right enclosed trailer can enhance your transportation capabilities and provide reliable service for years to come.

Contact us today and one of our representatives will get back to you as soon as possible on shop trailers for sale.
