Make My Trailer

Everything you need to know about the

7×16 Double Axle – South Georgia

1. Technical Features Table

→ → →

Standard FeaturesSouth Georgia
PRICE$5,550.00
EXTERIOR METALWhite or Black metal exterior (.080) Screwed metal exterior
AXLES3500lb leaf spring axles with 4" drop & Electric Brakes
V-NOSE V Nose (Standard)
ELECTRIC BRAKES Axles w/ Electric Brakes
DOME LIGHT12V Dome light with switch
WALLS/CEILING TUBING 1x1" steel tube in walls and ceiling
FLOOR TUBING 2x4" steel tube main rails
FLOOR CROSS-MEMBERS16" OC Floor Members
ROOF CROSS-MEMBERS24" OC Roof Members
WALL CROSS-MEMBERS16" OC Wall Members
LIGHTS LED Strip tail lights
INTERIOR HEIGHT75" (6'3") Interior height
REAR DOOR Ramp Door w/ Spring Assist & Extension Flap
PLUG / COUPLER (BALL)7-way Round elec. Plug/ 2 5/16" coupler
FENDERSAluminum fenders w/lights
SIDE DOOR32" RV style side door with flush lock
TIRESST205 15" RADIAL tires
RIMS/WHEELSSilver Mod Wheels
ROOF MATERIAL Galvalume roof
STONEGUARD24" Stoneguard on front
TONGUE JACK2000 lb tongue jack
HUBS EZ Lube Hubs
THERMA-PLY
WALL MATERIAL3/8" Premium plywood sidewalls
FLOOR MATERIAL3/4" plywood floor/Painted Underneath
SIDEWALL VENTSNon-powered roof vent
EMPTY WEIGHT2400 lbs
LOAD CAPACITY4600 lbs
GVWR7000 lbs
TONGUE WEIGHT339 lbs

2. Technical FAQ

What’s the EXTERNAL trailer length, width and height on the 7x16?

Overall Length: 19’6″ / 234 in (Breakdown: 16′ on the Box + 3’6″ on the Tongue) 20″ on the Vnose
Overall Width: 8’6″ / 102 in (Breakdown: 7′ on the Box + 9″ on each Fender)
Overall Height ( Diamond ): 8’4″ / 100 in (Breakdown: 7′ on the Box + 16″ from the ground to the box)
Overall Height (Anvil): 7’7″ / 91 in (Breakdown: 6’3″ on the Box + 16″ from the ground to the box)

What’s the INTERNAL trailer length, width and height on the 7x16?

Overall Length: 15’9″ Box (Breakdown: Subtract 3″ which counts for rear door & framing) plus 20″ on the Vnose
Overall Width: 6’8″ (Breakdown: Subtract 4″ (2″ on each side) which counts for plywood & framing)
Overall Height ( Diamond ): 7′
Overall Height (Anvil): 6’3″

What are the Rear Door Entry Measurements on the 7x16?

Width: 74″ (Breakdown: Subtract 10″ (5 on each side) which counts for plywood & framing)
Height ( Diamond ): 78″ (Breakdown: Subtract 6″ which counts for plywood & framing)
Height (Anvil): 69″ (Breakdown: Subtract 6″ which counts for plywood & framing)

What electric hookup do I need for my trailer lights?

7-way Round plug

What is the bolt pattern for the wheels?

5×4.5 (5 Lug)

What is your tire ply rating?

6 Ply

What is semi screw less?

Screws are 4′ apart instead of being every 2′

What paint do you typically use for underneath the plywood?

It’s an asphalt undercoating paint

Do you need HELP selecting your Custom Options?

We developed a section exclusively for Custom Options where we show sample photos and explain most popular options:

Click Here for More Information.

Here are examples of some of the most popular Custom Options:

– Blackout Package
– Electrical Package
– Insulation Package
– Rubber Flooring
– Etracks
– D-rings
– Windows
– Extended Tongue
– Extra Height
– Ladder Racks
– Finished Interior (Metal/Vinyl)
– Air Conditioner
– Lighting Options
– Axle Upgrades
– Concession Window
– Special Door Options
– Cabinets
– Barn Doors

3. Sample Photos

4. Sample Video

5. Sample Colors (Click to enlarge)

6. Purchase FAQ

Is there Financing available?

Click the link below for Financing Options:
https://makemytrailer.com/enclosed-trailer-financing-services/

Is there Delivery available?

Click the link below for Delivery Options:
https://makemytrailer.com/delivery/

What Paperwork comes with my Trailer?

30 Day Temporary Tag, Certificate of Origin and obviously your Title so you can register your brand new trailer

Are your prices Factory Direct?

Yes they are and also the reason why your trailer pick up is directly at the Factory.

Do we Charge Taxes?

We do not charge any taxes, that’s something that you pay when you register the trailer

When can I get my VIN number?

Yes, as soon as your trailer is ready we can provide your with your VIN number.

How can I pay my Deposit?

1) Credit or Debit Card (over the phone or invoice sent to your email)
2) Mail a Cashier’s Check
3) Wire Transfer

What happens after the Deposit is paid?

Once your deposit is confirmed we’ll send you an email just make everything official and after 24 hours (timeframe we provide in case of any changes) we will send your order to our production team so they can start working on your future top notch trailer

How long does our production team takes to the build your trailer?

It depends on 2 factors: The season and your Order so make sure to ask our awesome sales team for a more accurate completion timeframe but on average you might be looking between 2 to 4 weeks on standard order and about 3 to 5 weeks for orders with custom options.

Note: We do make exceptions so make sure to ask our sales team

Do I get any updates on my order?

We don’t usually provide any updates during the building process but we can definitely ask our production team how things are going but as soon as your trailer is ready, we will send you the completion email along with the instructions so you can start your pick up arrangements

Buy Now

By clicking Buy Now, you will be redirected to our secure PayPal checkout page. A deposit is required to reserve the standard version of this trailer size. The remaining balance, including any selected options or upgrades (such as A/C or insulation), will be due at pickup or delivery. Final price may vary depending on manufacturer and features. Please contact us to confirm details before completing your order.

7. Need a Quote?

SGC

Have you recently invested in an enclosed cargo trailer, or are you looking to maximize the lifespan and efficiency of your current one? Our comprehensive PDF guide is your ultimate companion to mastering the art of trailer maintenance!

Safeguard Your Investment:

10 Smart Ways to Prevent Trailer Theft!

Useful Article About:

South Georgias Premier 7x16 Double Axle Cargo Trailers: Top Quality & Value

Introduction: Why Your Next Haul Deserves South Georgia’s Best

When the job demands more than just transport—when it requires reliability, durability, and unwavering performance—the choice of equipment becomes paramount. For businesses, contractors, and individuals across Georgia, hauling valuable equipment, materials, or personal belongings is a critical task where compromise is not an option. A substandard trailer can lead to costly delays, damaged goods, and significant safety risks. This is why discerning buyers are turning to a solution engineered to exceed expectations, a tool built not just for the next job, but for years of dependable service.

The Indispensable Role of a Reliable Cargo Trailer

A cargo trailer is more than a simple box on wheels; it’s a mobile warehouse, a secure workshop, and a vital extension of your operational capacity. The right enclosed cargo trailer protects assets from weather and theft, streamlines logistics, and presents a professional image. In a competitive environment, the efficiency and security provided by a high-quality trailer are not luxuries but necessities for success, whether you’re a tradesperson moving tools between sites, a landscaper hauling equipment, or a motorsport enthusiast transporting your prized vehicle.

16 x 7 enclosed trailer

Unveiling South Georgia’s Premier 7×16 Double Axle Solution

Enter the 7×16 double axle cargo trailer from South Georgia Cargo. This specific model has emerged as the premier choice for those who demand a perfect balance of size, strength, and value. It represents the culmination of intelligent design, robust engineering, and a deep understanding of what users in South Georgia truly need. This article delves into the specific features and construction principles that elevate our 7×16 trailers from a simple commodity to an essential long-term investment, delivering unmatched quality and tangible value with every mile.

Unpacking “Premier Quality”: The Engineering Behind Our Trailers

The term “premier quality” is earned, not claimed. It’s a direct result of meticulous engineering, superior material selection, and a commitment to building trailers that withstand the rigors of real-world use. Every component, from the foundational frame to the smallest lighting fixture, is chosen and assembled to contribute to a final product defined by strength, safety, and longevity.

Foundations of Strength: Heavy-Duty Frame & Construction

The integrity of any cargo trailer begins with its skeleton. Our 7×16 models are built on a robust steel tube main frame, providing exceptional rigidity and resistance to flexing under heavy loads. The floor and wall crossmembers are strategically spaced to create a solid, integrated structure that distributes stress evenly. This heavy-duty construction ensures that the trailer maintains its shape and stability, protecting your cargo and providing a secure platform for years of demanding work. The use of high-grade plywood for the interior walls and floor further enhances this structural strength.

Superior Running Gear: Axles, Suspension, and Wheels for the Long Haul

A trailer is only as reliable as the components that connect it to the road. Our 7×16 model features a robust double axle configuration, which is critical for superior load distribution and enhanced stability, especially at highway speeds or on uneven surfaces. We utilize dependable leaf spring axles, renowned for their durability and ability to absorb road shock, providing a smoother ride for your cargo. This robust suspension system is paired with high-quality RADIAL tires, which offer a distinct advantage over older bias-ply alternatives by running cooler, lasting longer, and improving overall fuel efficiency.

Advanced Braking and Safety Systems

Safety is non-negotiable, especially when hauling significant weight. That’s why every one of our 7×16 double axle trailers comes standard with a full electric brakes system on both axles. This feature provides significantly more stopping power and control compared to unbraked trailers, allowing for shorter, more stable stops. This system, combined with a secure 2-5/16 inch coupler and a heavy-duty safety chain, ensures that the connection to your tow vehicle is both strong and responsive, giving you critical peace of mind on the road.

Aerodynamic Design and Exterior Durability

Performance and protection extend to the trailer’s exterior. The standard V-Nose design serves a dual purpose: it slices through the air more efficiently, reducing wind resistance and potentially improving your tow vehicle’s fuel economy. It also provides valuable extra interior space at the front of the trailer. The exterior is clad in durable screwed aluminum sheeting, protected by rugged aluminum fenders and finished with stylish ATP trim (Aluminum Tread Plate) on high-wear areas like the front corners, adding both resilience and a professional aesthetic.

Why the 7×16 Double Axle is Your Optimal Choice

While various trailer sizes exist, the 7×16 double axle configuration consistently proves to be the “sweet spot” for a vast range of users. It offers a unique combination of capacity, maneuverability, and stability that makes it one of the most versatile and popular trailers on the market.

Balanced Dimensions: Maximizing Space Without Sacrificing Maneuverability

The 7-foot width provides ample interior space for a wide variety of items, from ATVs and motorcycles to pallets of materials and contractor tools, without being excessively wide for navigating city streets or crowded job sites. The 16-foot length offers substantial volume for hauling, yet the trailer remains manageable to tow, back up, and park. This thoughtful balance prevents the unwieldy nature of larger trailers while providing significantly more capacity than smaller, single-axle options.

Unrivaled Load Capacity and Stability for Heavy-Duty Tasks

The inclusion of a second axle, or a double axle system, is the key to this trailer’s capability. A tandem axle design dramatically increases the Gross Vehicle Weight Rating (GVWR), allowing you to legally and safely haul heavier loads. It distributes the weight across four tires instead of two, creating a much more stable and smoother towing experience. This stability is especially noticeable on highways and during crosswinds, reducing sway and inspiring driver confidence when transporting valuable or heavy cargo.

A Foundation for Future Growth and Diverse Applications

Choosing a 7×16 double axle trailer is an investment in versatility. It’s a platform that can adapt as your needs evolve. For a new business, it provides the capacity for growth. For a homeowner, it can handle everything from a cross-country move to hauling landscaping materials. This adaptability ensures the enclosed cargo trailer remains a valuable asset for years, capable of serving multiple purposes and providing an excellent return on investment.

Feature-Rich Design: Enhancing Utility, Access, and Interior Protection

A premier trailer is defined by its thoughtful features that enhance everyday usability and protect the cargo within. Our 7×16 model is equipped with a suite of standard features designed to make loading, access, and working inside the trailer as efficient and secure as possible.

Seamless Access & Security Features

Effortless loading and unloading are crucial. The heavy-duty rear Ramp Door, complete with a spring-assist mechanism and flap extension, creates a smooth and sturdy incline for rolling equipment in and out. For quick access to items stored at the front, a 36″ Side Door with a secure RV-style latch provides a convenient secondary entry point. This dual-access system saves time and effort on any job.

Optimized Interior Environment for Your Valuables

The interior is designed to be both protective and functional. A standard interior height of approximately 6’3″ allows most users to stand and move around comfortably. To combat heat and moisture buildup, a non-powered roof vent facilitates crucial air circulation, protecting sensitive cargo from condensation. For visibility in low-light conditions, an integrated 12V Dome light provides essential interior illumination, powered directly by the tow vehicle.

Thoughtful Options and Customizations for Specific Needs

While our standard package is robust, we understand that every user has unique requirements. We offer a range of Options to tailor your trailer perfectly to your application. From adding ladder racks for contractors and upgrading to specialized flooring for vehicle transport, to installing additional tie-down points for securing specific cargo, our available customizations ensure your enclosed cargo trailer is perfectly equipped for its intended mission.

Versatility in Action: Tailored Solutions for South Georgia’s Needs

The true measure of a great cargo trailer is its ability to perform across a spectrum of demanding applications. The 7×16 double axle trailer is a proven workhorse, serving as a vital tool for professionals, entrepreneurs, and enthusiasts throughout Georgia.

The Go-To Trailer for Construction & Trade Professionals

For electricians, plumbers, builders, and general contractors, the 7×16 trailer is an indispensable mobile workshop. Its ample space securely organizes tools, ladders, and materials, protecting them from weather and job site theft. The double axle provides the capacity to haul heavy equipment like generators and compressors, while the ramp door makes loading and unloading a one-person job.

Empowering Small Businesses & Mobile Operations

Landscapers, mobile detailers, pressure washing services, and event vendors rely on the 7×16 for its ability to function as the core of their business. It can be outfitted with racks, shelving, and water tanks, transforming from a simple transport unit into a fully functional mobile operation. Its professional appearance also serves as a rolling billboard, enhancing brand visibility.

The Adventurer’s Choice: Hauling Recreational Vehicles

The 7×16 is perfectly sized for hauling a pair of ATVs, a UTV, multiple dirt bikes, or a golf cart. The sturdy ramp door and robust floor provide a secure platform for recreational vehicles. The enclosed design keeps expensive toys clean, dry, and safe from prying eyes during transit to the trails, campsite, or racetrack.

General Purpose Utility for Homeowners & More

Beyond commercial use, this trailer is a powerful tool for homeowners. It’s ideal for moving, making it possible to transport furniture and boxes in a single trip. It’s perfect for tackling large-scale landscaping projects, hauling away debris, or bringing home building materials for a renovation, offering a level of utility that far exceeds that of a standard pickup truck.

The South Georgia Cargo Value Promise: Investing in Long-Term Performance

In a market crowded with options, true value isn’t found in the lowest price tag but in the intersection of quality, durability, and fair pricing. The South Georgia Cargo promise is an investment in a product designed to perform reliably for years, ultimately saving you money and time.

Defining True Value: Quality That Endures and Saves

Our approach to value is simple: build it right, so it lasts. By using superior components like RADIAL tires, heavy-duty spring axles, a robust steel frame, and bright, long-lasting LED Strip tail lights, we build trailers that require less maintenance and suffer fewer breakdowns. This reliability translates directly to lower ownership costs and more uptime for your business or personal projects.

Transparency in Pricing and Accessible Financing Solutions

We believe in straightforward, honest pricing without hidden fees. Our goal is to provide the best possible trailer for your money. To make ownership accessible to everyone, we offer a variety of financing solutions, including options for those with varying credit histories, ensuring you can acquire the tool you need to succeed without delay.

Standing Apart from the Crowd: Why Our “Premier” Trailers are a Smart Investment

Many trailers look similar from a distance, but the difference lies in the details you can’t always see—the quality of the welds, the grade of the steel, the reliability of the wiring. A South Georgia Cargo trailer is a smart investment because it’s built by people who understand the demands of hauling in the Southeast. It’s an investment in safety, durability, and peace of mind.

Your Dedicated Local Partner: South Georgia Cargo Expertise

Choosing the right trailer is a significant decision, and having an expert partner to guide you through the process is invaluable. South Georgia Cargo is more than just a dealer; we are a dedicated, locally-rooted team committed to your success.

Deep Roots in South Georgia: Understanding Your Local Needs

Our presence in South Georgia isn’t just a location—it’s our home. We understand the local economy, the types of jobs our customers perform, and the road conditions they face. This firsthand knowledge allows us to recommend and provide trailers that are perfectly suited to the challenges and opportunities right here in our community.

Expert Guidance and Unparalleled Customer Service

Our team possesses deep product knowledge and is passionate about helping you find the perfect hauling solution. We take the time to listen to your needs, explain the benefits of different features, and ensure you leave with a trailer that not only meets but exceeds your expectations. Our commitment to service continues long after the sale.

enclosed 7x16 trailer

A Reputation Built on Trust and Quality in the Cargo Trailer Industry

We have earned a strong reputation across Georgia and beyond by consistently delivering high-quality trailers and standing behind our products. Our customers—from large construction firms to individual homeowners—trust us because they know a trailer from South Georgia Cargo is a trailer built to last, representing the pinnacle of quality and value.
