Make My Trailer

Everything you need to know about the

6x10 Single Axle with Blackout Package

1. Technical Features Table

→ → →

Standard FeaturesRolling Vault (Economy)
PRICE$3,445.00
EXTERIOR METAL.024 metal exterior Semi-Screwless exterior
AXLES2990 lb Spring axle with 4" drop and EZ Lube Hubs
V-NOSE V-Nose with vertical ATP trim
DOME LIGHT12V Dome light with switch
WALLS/CEILING TUBING1"x1½" steel tube in walls and ceiling
FLOOR TUBING 2x3" Steel Tube Main Rails
FLOOR CROSS-MEMBERSFloor crossmembers 16" O.C.
ROOF CROSS-MEMBERSRoof members 24" O.C.
WALL CROSS-MEMBERSWall members 16" O.C.
LIGHTS LED Strip tail lights
INTERIOR HEGHT75" (6'3") Interior height
REAR DOOR Double rear door w/bar lock or ramp
PLUG / COUPLER (BALL)4-way Bargman plug  2" coupler
SIDE DOOR32" RV style side door with flush lock
FENDERSAluminum Fender w/Lights
TIRES15" Tires
RIMS/WHEELSSilver Mod Wheels
ROOF MATERIAL Galvalume roof
WALL MATERIAL3/8" Plywood Walls
FLOOR MATERIAL3/4" Plywood Floor
EMPTY WEIGHT1200 lbs
LOAD CAPACITY1790 lbs
GVWR2990 lbs
TONGUE WEIGHT165 lbs

2. Technical FAQ

What’s the EXTERNAL trailer length, width and height on the 6x10?

Overall Length: 13’6″ / 162 in (Breakdown: 10′ on the Box + 3’6″ on the Tongue) 20″ on the Vnose
Overall Width: 7’6″ / 90 in (Breakdown: 6′ on the Box + 9″ on each Fender)
Overall Height: 7’7″ / 91 in (Breakdown: 6’3” on the Box + 16″ from the ground to the box)

What’s the INTERNAL trailer length, width and height on the 6x10?

Overall Length: 9’9″ Box (Breakdown: Subtract 3″ which counts for rear door & framing) plus 20″ on the Vnose
Overall Width: 5’8″ (Breakdown: Subtract 4″ (2″ on each side) which counts for plywood & framing)
Overall Height: 6’3″

What are the Rear Door Entry Measurements on the 6x10?

Width: 62″ (Breakdown: Subtract 10″ (5 on each side) which counts for plywood & framing)
Height: 69″ (Breakdown: Subtract 6″ which counts for plywood & framing)

Does the 6x10 trailer come with electric brakes?

No it doesn’t but they’re available as a custom option.

Side Note: If the combined weight of the trailer and its load approaches or exceeds 3,000 pounds, many jurisdictions require brakes on the trailer. However, a 4×6 enclosed trailer, given its size, is unlikely to reach this weight limit when fully loaded, as they typically have a lower payload capacity.

Safety Considerations

Driving Conditions: If you plan to tow your trailer in hilly or mountainous areas, or if you’ll be driving in a lot of stop-and-go traffic, having electric brakes can significantly improve safety by reducing stopping distances and improving vehicle control.

Emergency Handling: Electric brakes can offer better control in emergency braking situations, reducing the risk of accidents.

Wear on Vehicle Brakes: Using a trailer with its own braking system can reduce wear and tear on your vehicle’s brakes, especially important for frequent towing or heavy loads.

What electric hookup do I need for my trailer lights?

4-way flat plug

What is the bolt pattern for the wheels?

5×4.5 (5 Lug)

What is your tire ply rating?

6 Ply

What is semi screw less?

Screws are 4′ apart instead of being every 2′

What paint do you typically use for underneath the plywood?

It’s an asphalt undercoating paint

Do you need HELP selecting your Custom Options?

We developed a section exclusively for Custom Options where we show sample photos and explain most popular options:

Click Here for More Information.

Here are examples of some of the most popular Custom Options:

– Blackout Package
– Electrical Package
– Insulation Package
– Rubber Flooring
– Etracks
– D-rings
– Windows
– Extended Tongue
– Extra Height
– Ladder Racks
– Finished Interior (Metal/Vinyl)
– Air Conditioner
– Lighting Options
– Axle Upgrades
– Concession Window
– Special Door Options
– Cabinets
– Barn Doors

3. Sample Photos

4. Sample Video

5. Sample Colors (Click to enlarge)

6. Purchase FAQ

Is there Financing available?

Click the link below for Financing Options:
https://makemytrailer.com/enclosed-trailer-financing-services/

Is there Delivery available?

Click the link below for Delivery Options:
https://makemytrailer.com/delivery/

What Paperwork comes with my Trailer?

30 Day Temporary Tag, Certificate of Origin and obviously your Title so you can register your brand new trailer

Are your prices Factory Direct?

Yes they are and also the reason why your trailer pick up is directly at the Factory.

Do we Charge Taxes?

We do not charge any taxes, that’s something that you pay when you register the trailer

When can I get my VIN number?

Yes, as soon as your trailer is ready we can provide your with your VIN number.

How can I pay my Deposit?

1) Credit or Debit Card (over the phone or invoice sent to your email)
2) Mail a Cashier’s Check
3) Wire Transfer

What happens after the Deposit is paid?

Once your deposit is confirmed we’ll send you an email just make everything official and after 24 hours (timeframe we provide in case of any changes) we will send your order to our production team so they can start working on your future top notch trailer

How long does our production team takes to the build your trailer?

It depends on 2 factors: The season and your Order so make sure to ask our awesome sales team for a more accurate completion timeframe but on average you might be looking between 2 to 4 weeks on standard order and about 3 to 5 weeks for orders with custom options.

Note: We do make exceptions so make sure to ask our sales team

Do I get any updates on my order?

We don’t usually provide any updates during the building process but we can definitely ask our production team how things are going but as soon as your trailer is ready, we will send you the completion email along with the instructions so you can start your pick up arrangements

Buy Now

By clicking Buy Now, you will be redirected to our secure checkout page. A deposit is required to reserve this trailer, and the remaining balance must be paid at pickup or delivery. Final price may vary depending on manufacturer and options. Please contact us to confirm details before completing your order.

7. Need a Quote?

Have you recently invested in an enclosed cargo trailer, or are you looking to maximize the lifespan and efficiency of your current one? Our comprehensive PDF guide is your ultimate companion to mastering the art of trailer maintenance!

Safeguard Your Investment:

10 Smart Ways to Prevent Trailer Theft!

Useful Article About:

Get Ready to Haul with Confidence: Our 6x10 Single Axle Enclosed Trailer with Blackout Package

When it comes to transporting valuable equipment, supplies, or personal treasures, the journey is just as important as the destination. The difference between a stressful trip and a smooth, confident haul often comes down to the quality of your equipment. You need a trailer that not only protects your cargo but also reflects your professionalism and style. It must be reliable, easy to handle, and versatile enough to meet the demands of any task, from a weekend race to a cross-town move for a growing business. This is where performance meets presence, and functionality pairs with a bold aesthetic.

6 x 10 enclosed trailer

Introduction: Your Solution for Confident and Stylish Hauling

Introduction: Your Solution for Confident and Stylish Hauling

For those who demand more than just basic transportation, the 6×10 single axle enclosed trailer with the Blackout Package emerges as the definitive solution. This isn’t merely a box on wheels; it’s a carefully engineered tool designed to provide peace of mind, operational efficiency, and an undeniable visual impact. It’s built for the discerning user who understands that their equipment is an extension of their brand or passion.

Why Confidence is Key in Every Haul

Every time you hitch up a trailer, you’re placing your trust in its construction, its components, and its ability to safeguard what’s inside. Confidence isn’t a luxury; it’s a necessity. It’s the assurance that your trailer will track true on the highway, that its doors will remain secure, and that your cargo will arrive in the same condition it left. This confidence allows you to focus on the road ahead, not worry about the load behind you.

Discover the Perfect Partner for Your Cargo

Imagine a trailer that effortlessly combines rugged durability with a sleek, modern design. The 6×10 enclosed cargo trailer is the perfect size for a multitude of applications—large enough to be highly useful yet compact enough for exceptional maneuverability. When enhanced with the striking Blackout Package, it transforms from a simple utility item into a statement piece, making it the ideal partner for your valuable cargo.

Why Confidence is Key in Every Haul

Introducing Our Featured 6×10 Single Axle Enclosed Trailer with Blackout Package

We are proud to present a cargo trailer that embodies both strength and style: our 6×10 single axle enclosed model. This trailer is engineered for performance, featuring a robust frame, a dependable suspension system, and user-friendly access points. What truly sets it apart is the available Blackout Package, an aesthetic and functional upgrade that caters to those who want their equipment to stand out from the crowd.

The Aesthetic Edge & Practical Benefits of the Blackout Package

The Blackout Package is a comprehensive cosmetic upgrade that transforms the trailer’s appearance from standard to stunning. It typically includes black aluminum wheels, black trim, black diamond plate stone guard, and black fenders. This cohesive, all-black theme creates a bold, aggressive look that is highly sought after by motorsports enthusiasts, high-end contractors, and anyone looking to project a premium image. It’s a visual declaration of quality and attention to detail.

Stealth and Style for Every Journey: More Than Just Good Looks

While the visual appeal is undeniable, the Blackout Package offers more than just style. The powder-coated or painted black components can offer an additional layer of corrosion resistance compared to standard finishes. The dark aluminum wheels are not only stylish but also maintain the lightweight, rust-proof benefits of standard aluminum. This package ensures your trailer looks as good on its hundredth trip as it did on its first, blending stealthy sophistication with road-ready resilience.

Durability and Low Maintenance Appeal of the Blackout Finish

Making a Statement: Professionalism and Undisputed Presence

Arriving at a job site or event with this trailer sends a clear message. The clean lines of the semi-screwless exterior, combined with the assertive stance of the Blackout Package, convey a sense of professionalism and seriousness. For a business, this can enhance brand perception. For a hobbyist, such as a race trailer owner, it adds to the competitive and polished presence in the paddock.

Optimal Payload Capacity for Your Needs: Balancing Size and Strength

A trailer’s true worth is measured by its ability to carry a load safely. The 6×10 model is designed to offer a significant payload capacity, perfectly balanced for a single axle configuration. This allows you to transport heavy items like motorcycles, landscaping equipment, or a full load of tools without requiring a heavy-duty tow vehicle. It hits the sweet spot between utility and efficiency, ensuring you have the capacity you need without unnecessary bulk.

The Smart Choice: Why a 6×10 Single Axle Enclosed Trailer is Right for You

The 6×10 footprint is one of the most versatile sizes available. It’s an ideal choice for contractors, small business owners, and outdoor enthusiasts. The enclosed trailer market is growing, with one report anticipating a compound annual growth rate of 3.9% for the segment. This indicates a strong, sustained demand for versatile and secure hauling solutions. Choosing a 6×10 enclosed trailer is not just a purchase; it’s a strategic investment in a popular and highly functional asset.

Maneuverability and Ease of Towing: Perfect for Any Driver

One of the greatest advantages of a single axle trailer of this size is its superior maneuverability. Navigating tight job sites, crowded event parking lots, or simply backing into a driveway is significantly easier than with a larger, tandem-axle unit. Paired with a reliable tongue jack for easy hitching and unhitching, this trailer is user-friendly for both seasoned towers and those new to hauling.

Optimal Payload Capacity for Your Needs: Balancing Size and Strength

Cost-Effectiveness and Efficiency: Smart Investment for Diverse Uses

This trailer represents a smart financial decision. The single axle design has fewer moving parts—fewer tires, bearings, and brake components—which translates to lower initial cost and reduced long-term maintenance expenses. Its manageable weight contributes to better fuel efficiency for the tow vehicle, further lowering the total cost of ownership over its lifespan.

Single Axle Advantages: Simplicity, Agility, and Reduced Maintenance

The single axle is the key to this trailer’s agility. With only one pivot point per side, tight turns are executed with ease, and tire scrubbing is eliminated. This simplicity also means maintenance is more straightforward. The robust leaf spring axle provides a reliable suspension that effectively dampens road imperfections, protecting your cargo and ensuring a smooth ride.

Secure and Convenient Access Points

Functionality is defined by accessibility. This trailer is typically equipped with a spring-assisted rear ramp door, making loading and unloading heavy or wheeled items like dollies and motorcycles a simple task. Additionally, a side door, often built in an RV style, provides quick access to items at the front of the cargo trailer without needing to lower the main ramp. Custom options like barn doors can also be configured for users who prefer them for forklift loading or other specific needs.

Built for the Long Haul: Key Exterior Features for Unwavering Confidence

Robust Construction and Seamless Exterior

Confidence starts with the frame, but the exterior skin provides the first line of defense. Our trailer features a semi-screwless exterior, which minimizes the number of potential failure points for water intrusion while offering a clean, sleek appearance that complements the Blackout Package. Protection against the elements is further guaranteed by a durable Galvalume roof, known for its exceptional corrosion resistance. Lightweight and rust-proof aluminum fenders round out the exterior, providing durable protection against road debris.

6×10 trailer

Dependable Running Gear for Smooth Journeys

The foundation of a confident haul lies in the running gear. This trailer rides on high-quality radial tires, which offer superior longevity, better heat dissipation, and a smoother ride compared to older bias-ply designs. These tires are mounted on a 3500lb leaf spring axle, a time-tested system known for its durability and load-handling capabilities. For maximum safety, the axle is equipped with electric brakes, providing crucial stopping power that works in sync with your tow vehicle.

Secure and Convenient Access Points

Beyond the primary doors, details matter. High-quality locks and latches on both the side door and ramp door ensure your enclosed cargo remains secure. With cargo theft on the rise—Penske Truck Leasing reported that theft events were up 59% in 2023—having a physically secure enclosed trailer is more critical than ever. Optional loading lights can be added to illuminate the ramp and interior, enhancing safety and convenience during early morning or late-night operations.

Who Needs This Trailer? Ideal Applications for the 6×10 Blackout

Interior Design: Maximizing Your Cargo’s Safety and Versatility

The interior of the trailer is a blank canvas ready for any task. The walls and floor are constructed from durable, high-quality wood, providing a sturdy base for your cargo. The thoughtful design ensures a snag-free interior, ready to be customized with shelving, racks, or wheel chocks to perfectly suit your specific hauling requirements, whether it’s for a motorcycle trailer or a mobile workshop.

Ample Interior Height for Diverse Loads: Fitting More Than You Think

A key specification for any enclosed trailer is its interior height. Our 6×10 models typically offer generous vertical clearance, allowing you to transport taller items like refrigerators, stacked boxes, or UTVs that might not fit in a standard utility trailer. This extra height dramatically increases the trailer’s versatility, ensuring you won’t be limited by your cargo’s dimensions.

Durable Flooring and Walls: Ready for Anything

The floor is the backbone of the cargo area, and ours is built to withstand heavy use. Constructed from ¾-inch engineered wood, it provides a solid, stable surface that resists wear and tear. The walls are similarly robust, offering protection for your cargo and a sturdy surface for installing tie-down points or organizational systems.

Securing Your Valuables: Essential Tie-Down Options

Pre-Trip Inspection Checklist: Ensuring Safe Journeys

Confidence is maintained through diligence. Before every trip, a quick inspection is essential. Check tire pressure on the radial tires, confirm that the electric brakes are functioning, test all lights, and ensure the coupler is securely attached to the hitch ball. Verify that the tongue jack is fully retracted and that all doors are securely latched. This simple routine is the best way to guarantee a safe and uneventful journey.

Who Needs This Trailer? Ideal Applications for the 6×10 Blackout

The versatility of the 6×10 enclosed cargo trailer with the Blackout Package makes it a perfect fit for a wide range of users who prioritize security, style, and functionality:

  • Contractors and Tradespeople: Securely transport valuable tools and materials, presenting a professional image to clients.
  • Motorsports Enthusiasts: An ideal race trailer for a single motorcycle, karts, or all the necessary gear and spare parts for a race weekend.
  • Landscapers: Protect expensive mowers and equipment from weather and theft.
  • Small Business Owners: Use it for deliveries, mobile services, or as a pop-up retail space, capitalizing on the growing e-commerce market that saw a 7.7% increase in sales in Q2 2023.
  • Outdoor Adventurers: Haul ATVs, kayaks, and camping gear, keeping it secure and ready for the next adventure.

Conclusion

The 6×10 single axle enclosed trailer with the Blackout Package is more than just a hauling solution; it is a declaration of quality, capability, and confidence. It masterfully combines a rugged, durable structure with a striking aesthetic that sets you apart. From its maneuverable single axle design and dependable radial tires to its secure access points and semi-screwless exterior, every feature is designed to provide peace of mind and operational excellence.

This trailer is a smart investment in efficiency and security. Whether you are growing a business, pursuing a passion, or simply need a reliable way to transport your goods, this enclosed cargo trailer delivers on all fronts. When you are ready to purchase, we offer straightforward financing options to make ownership accessible. We will answer all your questions through our Purchase FAQ and ensure you receive the necessary Certificate of Origin for a smooth registration process. Get ready to haul with confidence and style. Contact us today to explore custom options and find the perfect trailer for your needs.
