Make My Trailer

Everything you need to know about the

8.5x18 Double Axle with Ladder Racks

1. Technical Features Table

→ → →

Standard FeaturesQuality
PRICE$6,918.00
EXTERIOR METAL.024 White metal exterior Semi-Screwless exterior
AXLESTandem 3500 lb Spring axles w/4" drop and
V-NOSE V Nose (Standard)
ELECTRIC BRAKES Axles w/ Electric Brakes
DOME LIGHT12V Dome light with switch
WALLS/CEILING TUBING 1"x1" steel tube in walls and ceiling
FLOOR TUBING 6" Tube Main Frame
FLOOR CROSS-MEMBERSFloor Members 16" O.C.
ROOF CROSS-MEMBERSRoof Members 24" O..C
WALL CROSS-MEMBERSWall Members 16" O.C.
LIGHTS LED Strip tail lights
INTERIOR HEIGHT6'6" (78") Interior Height
REAR DOOR Rear Ramp w/ Spring Assists w/Flap
PLUG / COUPLER (BALL)7-way Round elec. Plug 2 5/16" coupler
FENDERSAluminum fenders w/lights
SIDE DOOR32" RV style side door with flush lock
ATPV-Nose with vertical ATP trim
TIRES15" Tires
RIMS/WHEELSSilver Mod Wheels
ROOF MATERIAL Galvalume roof
STONEGUARD24" Stoneguard on front
TONGUE JACK2000 lb tongue jack
HUBS EZ Lube Hubs
WALL MATERIALPremium 3/8" plywood sidewalls
FLOOR MATERIAL3/4" plywood floor/painted underneath
SIDEWALL VENTSNon-powered roof vent or sidewall
DRINGS4 D-Rings in Floor
BEAVERTAILBeavertail Frame
EMPTY WEIGHT3000 lbs
LOAD CAPACITY4000 lbs
GVWR7000 lbs
TONGUE WEIGHT450 lbs

2. Technical FAQ

What’s the EXTERNAL trailer length, width and height on the 8.5x18?

Overall Length: 21’6″ / 258 in (Breakdown: 18′ on the Box + 3’6″ on the Tongue) 20″ on the Vnose
Overall Width: 8’6″/ 102 in (Breakdown: 8’6″ on the Box)
Overall Height ( Diamond ): 8’4″ / 100 in (Breakdown: 7′ on the Box + 16″from the ground to the box)
Overall Height (Anvil): 7’10” / 94 in (Breakdown: 6’6″ on the Box + 16″from the ground to the box)

What’s the INTERNAL trailer length, width and height on the 8.5x18?

Overall Length: 17’9″ Box (Breakdown: Subtract 3″ which counts for rear door & framing) plus 20″ on the Vnose
Overall Width: 8′ Wall to Wall (Breakdown: Subtract 3″ (each wall) which counts for framing & Plywood)
Width Between Wheel Boxes: 81 inches (Breakdown: Subtract 7.5″ (each side) which counts for wheel boxes
Overall Height ( Diamond ): 7′
Overall Height (Anvil): 6’6″

What are the Rear Door Entry Measurements on the 8.5x18?

Width: 90″ (Breakdown: Subtract 12″ (6 on each side) which counts for plywood & framing)
Height ( Diamond ): 78″ (Breakdown: Subtract 6″ which counts for plywood & framing)
Height (Anvil): 72″ (Breakdown: Subtract 6″ which counts for plywood & framing)

What electric hookup do I need for my trailer lights?

7-way Round plug

What is the bolt pattern for the wheels?

5×4.5 (5 Lug)

What is your tire ply rating?

6 Ply

What is semi screw less?

Screws are 4′ apart instead of being every 2′

What paint do you typically use for underneath the plywood?

It’s an asphalt undercoating paint

Do you need HELP selecting your Custom Options?

We developed a section exclusively for Custom Options where we show sample photos and explain most popular options:

Click Here for More Information.

Here are examples of some of the most popular Custom Options:

– Blackout Package
– Electrical Package
– Insulation Package
– Rubber Flooring
– Etracks
– D-rings
– Windows
– Extended Tongue
– Extra Height
– Ladder Racks
– Finished Interior (Metal/Vinyl)
– Air Conditioner
– Lighting Options
– Axle Upgrades
– Concession Window
– Special Door Options
– Cabinets
– Barn Doors

3. Sample Photos

4. Sample Video

5. Sample Colors (Click to enlarge)

6. Purchase FAQ

Is there Financing available?

Click the link below for Financing Options:
https://makemytrailer.com/enclosed-trailer-financing-services/

Is there Delivery available?

Click the link below for Delivery Options:
https://makemytrailer.com/delivery/

What Paperwork comes with my Trailer?

30 Day Temporary Tag, Certificate of Origin and obviously your Title so you can register your brand new trailer

Are your prices Factory Direct?

Yes they are and also the reason why your trailer pick up is directly at the Factory.

Do we Charge Taxes?

We do not charge any taxes, that’s something that you pay when you register the trailer

When can I get my VIN number?

Yes, as soon as your trailer is ready we can provide your with your VIN number.

How can I pay my Deposit?

1) Credit or Debit Card (over the phone or invoice sent to your email)
2) Mail a Cashier’s Check
3) Wire Transfer

What happens after the Deposit is paid?

Once your deposit is confirmed we’ll send you an email just make everything official and after 24 hours (timeframe we provide in case of any changes) we will send your order to our production team so they can start working on your future top notch trailer

How long does our production team takes to the build your trailer?

It depends on 2 factors: The season and your Order so make sure to ask our awesome sales team for a more accurate completion timeframe but on average you might be looking between 2 to 4 weeks on standard order and about 3 to 5 weeks for orders with custom options.

Note: We do make exceptions so make sure to ask our sales team

Do I get any updates on my order?

We don’t usually provide any updates during the building process but we can definitely ask our production team how things are going but as soon as your trailer is ready, we will send you the completion email along with the instructions so you can start your pick up arrangements

Buy Now

By clicking Buy Now, you will be redirected to our secure PayPal checkout page. A deposit is required to reserve the standard version of this trailer size. The remaining balance, including any selected options or upgrades (such as A/C or insulation), will be due at pickup or delivery. Final price may vary depending on manufacturer and features. Please contact us to confirm details before completing your order.

7. Need a Quote?

Have you recently invested in an enclosed cargo trailer, or are you looking to maximize the lifespan and efficiency of your current one? Our comprehensive PDF guide is your ultimate companion to mastering the art of trailer maintenance!

Safeguard Your Investment:

10 Smart Ways to Prevent Trailer Theft!

Useful Article About:

Boost Your Job Site Efficiency with Our 8.5x18 Double Axle with Ladder Racks Enclosed Trailers

In the fast-paced world of construction and skilled trades, efficiency isn’t just a goal—it’s the cornerstone of profitability and reputation. With the construction industry projected to grow faster than all other industries over the next decade, according to the U.S. Bureau of Labor Statistics, maximizing productivity is more critical than ever. Yet, daily operations are often bogged down by disorganized tools, inefficient transport, and the constant threat of equipment damage or theft. For professionals who overwhelmingly prefer owning their gear, as noted in a report where 73.5% of construction companies favor ownership over renting, protecting and organizing these assets is paramount. It’s time to move beyond makeshift solutions and embrace a system designed to streamline your workflow from the moment you leave for a job until the last tool is packed away. This is where a dedicated, purpose-built mobile workspace changes the game.

enclosed trailer 8.5 x18

The Daily Grind: Unpacking Job Site Inefficiencies

The gap between a productive day and a frustrating one often lies in the small, compounding inefficiencies that plague job sites. These seemingly minor issues add up, creating significant drains on time, money, and morale.

The Hidden Costs of Disorganization: Lost Time, Damaged Gear, and Frustration

Every minute spent searching for a specific tool, untangling cords, or shifting materials to access equipment is a minute you’re not billing. This disorganization leads directly to project delays and budget overruns. Furthermore, when tools are piled haphazardly in the back of a truck or van, they are susceptible to damage from shifting during transit or exposure to the elements, leading to costly repairs and replacements. The constant frustration of a chaotic workspace can also lower team morale and productivity.

The Challenges of Transporting Essential Equipment Safely and Efficiently

Transporting large, bulky, or delicate equipment presents a daily logistical hurdle. Open-bed trucks offer limited protection from weather, leaving expensive tools vulnerable to rain, snow, and sun damage. Securing loads with straps and tarps is time-consuming and often provides inadequate security against theft. Moving from one site to another becomes a lengthy process of loading and unloading, increasing the risk of both equipment damage and personal injury.

Minimizing Downtime: Every Minute Counts for Contractors

Downtime is the enemy of profitability. Whether it’s a delay caused by a missing tool, a piece of equipment damaged in transit, or the need to make an unscheduled trip back to the shop for a forgotten item, every non-productive moment impacts the bottom line. In an industry where deadlines are tight and labor is a significant expense, minimizing these interruptions is essential for maintaining a competitive edge and ensuring project success.

Introducing Your Mobile Command Center: The 8.5×18 Double Axle Enclosed Trailer

Imagine a solution that directly addresses these inefficiencies—a secure, organized, and mobile hub for your entire operation. The 8.5×18 Double Axle Enclosed Trailer is not just a means of transport; it’s a strategic asset designed to function as your on-site command center.

Designed for the Demands of Construction and Trade Professionals

This specific trailer configuration hits the sweet spot for professionals. It’s built to withstand the rigors of daily use, from rough job site terrain to highway travel. The enclosed design provides a controlled environment, protecting your valuable tools and materials from weather and prying eyes. It’s a professional-grade solution for a demanding professional environment, reflecting the quality of your work before you even step on site.

An All-in-One Solution for Productivity and Protection

By consolidating storage, transport, and organization into one mobile unit, this trailer eliminates the need for multiple vehicles or makeshift storage systems. It serves as a secure locker for your gear, a workshop on wheels, and a reliable transport vehicle rolled into one. This integration is the key to transforming a chaotic workflow into a streamlined, repeatable process that boosts productivity and safeguards your assets around the clock.

The Synergy of Size and Strength: Optimizing Your Workflow

The effectiveness of this mobile command center hinges on its core design: a perfect balance of generous space and robust strength, ensuring it can handle the demands of your business without compromise.

Generous 8.5×18 Dimensions: More Than Just Space

The 8.5-foot width and 18-foot length provide ample interior volume to create a highly functional workspace. This isn’t just empty space; it’s a canvas for ultimate organization. You have room for built-in shelving, workbenches, and dedicated storage for everything from power tools to raw materials. This generous footprint allows you to organize your equipment logically, creating a mobile “Tool Barn trailer” where every item has its place. This systematic approach drastically reduces time spent searching for tools and allows for a more efficient on-site setup.

Unmatched Stability & Capacity: The Double Axle Advantage

The double axle, or Tandem Axle, design is a critical feature for any serious professional. It provides superior stability on the road, especially when carrying heavy or unevenly distributed loads. This design significantly enhances safety by improving braking performance and providing redundancy in case of a tire failure. More importantly, a Tandem Axle configuration offers a higher gross vehicle weight rating (GVWR), empowering you to haul more materials, heavier equipment, and larger tools, reducing the need for multiple trips and saving valuable time and fuel.

Ladder Racks: Revolutionizing On-Site Accessibility and Safety

While the enclosed space is foundational, the integrated ladder racks are the feature that truly multiplies efficiency, turning a great trailer into an indispensable tool.

Instant Access, Maximum Safety with Integrated Ladder Racks

Storing bulky ladders inside an enclosed cargo trailer consumes valuable floor and wall space that could be used for tools and materials. Exterior ladder racks solve this problem by providing a dedicated, secure, and easily accessible storage location. This allows you to grab your ladders the moment you arrive on-site without having to unload other equipment first. This immediate access streamlines the start of any job requiring work at height, directly contributing to a safer and more efficient workflow.

Protecting Your Investment: Secure Transport for Ladders

Ladders are a significant investment and are prone to damage if not transported correctly. Tossing them in the back of a truck can lead to dents, bent rungs, and other structural damage that compromises safety. Purpose-built ladder racks secure your ladders firmly in place, protecting them from the bumps and vibrations of the road and preventing them from becoming a hazard to other drivers.

Streamlining Setup and Teardown Times for Peak Productivity

In an industry facing significant labor demands, with firms needing to attract an estimated 546,000 additional workers in 2023 alone, every saved minute of labor is critical. Integrated ladder racks play a huge role in this. They eliminate the time-consuming process of strapping ladders down on a truck rack or wrestling them out from inside a crowded trailer. This simple but effective design feature can shave precious minutes off both setup and teardown times each day, adding up to hours of saved labor costs each month.

Features That Drive Day-to-Day Efficiency and Peace of Mind

Beyond the core structure, it’s the thoughtful details and quality components that elevate this trailer from simple storage to a high-performance work tool.

Secure Storage: Protecting Your Valuable Assets

Trailer theft is a serious concern for any contractor. This enclosed trailer serves as a robust deterrent. With a solid structure and secure locking mechanisms on both the side and rear doors, your equipment is shielded from opportunistic thieves. Each trailer comes with a unique VIN number, essential for registration, insurance, and recovery in the unfortunate event of theft. This secure environment gives you the confidence to leave your tools on-site, saving you from the daily hassle of unloading and reloading your entire kit.

Thoughtful Design for Optimal Operation and Longevity

Efficiency is built into every component. Bright, long-lasting LED lights illuminate the interior, allowing you to find what you need quickly, even during early morning starts or late-night finishes. Durable aluminum door hold backs keep doors securely open for easy, hands-free loading. For tasks that produce fumes or dust, aluminum sidewall vents provide crucial ventilation, maintaining a safer working environment inside your mobile workshop.

Connectivity and Reliability: The 7-way Round Plug

Reliable connectivity to your tow vehicle is non-negotiable. The industry-standard 7-way round plug ensures a secure and weatherproof connection for all your trailer’s electrical systems, including the brakes and all LED lights. This dependable link is crucial for safe towing, ensuring your trailer functions as a seamless extension of your vehicle every time you hit the road.

The Long-Term Investment: Durability Meets Sustained Efficiency

Purchasing a high-quality trailer is not an expense; it’s a long-term investment in your business’s operational capacity and profitability.

Built to Last: Superior Materials and Construction

This trailer is engineered for longevity. A one-piece Galvalume roof offers exceptional corrosion resistance and leak protection, safeguarding your assets from the elements year after year. For even greater durability, options like a reinforced roof are available to handle additional loads. The undercarriage is protected by a tough asphalt undercoating paint, which defends against rust, road salt, and debris, preserving the structural integrity of the frame for years of reliable service.

Minimizing Downtime and Maintenance Costs

The use of high-quality materials and robust construction translates directly to less downtime and lower maintenance expenses. Features like stylish but sturdy Liger Aluminum rims reduce unsprung weight and resist corrosion better than standard steel wheels. The entire package is designed to withstand the rigors of the job site, minimizing the risk of breakdowns and repairs that can pull you off a paying job.

A Reliable Partner for Years of Uninterrupted Service

When you invest in a well-built enclosed trailer from a reputable manufacturer like Titanium Cargo or Boss Cargo Trailers, you are acquiring a reliable partner for your business. This asset will consistently deliver value by protecting your equipment, streamlining your workflow, and presenting a professional image to your clients day in and day out.

From Purchase to Productivity: Getting Your Efficiency Solution

Acquiring the perfect trailer for your needs is a straightforward process designed to get you up and running as quickly as possible.

Ready-Made Efficiency: The Advantage of a Pre-Configured Package

This 8.5×18 double axle enclosed trailer with ladder racks is a pre-configured package designed around the most common needs of trade professionals. This proven layout provides a powerful, out-of-the-box solution that allows you to immediately benefit from enhanced organization and efficiency without the complexities of a fully custom build.

Tailored for Your Needs: Explore Custom Options (Briefly)

While the standard package is exceptional, we understand that every business has unique requirements. A wide range of custom options and trailer package options are available to create your perfect trailer. From adding aluminum toolboxes and custom shelving to upgrading to a sleek Blackout Race Trailer aesthetic, you can tailor your mobile workspace to your exact specifications. Many providers even offer an online trailer builder to visualize your ideal setup. This adaptability is why these platforms can also be configured for uses as diverse as Motorcycle Trailers, a Toy Hauler, or even concession trailers.

Flexible Acquisition: Making Efficiency Accessible

Various purchasing and financing options are available to make this essential business upgrade accessible. Investing in a tool that generates a clear return through saved time, protected assets, and increased productivity is one of the smartest financial decisions a contractor can make.

Conclusion: Elevate Your Job Site with Unrivaled Efficiency

In today’s competitive construction landscape, operational efficiency is the ultimate advantage. The constant drain of disorganization, wasted time, and the risk of damaged or stolen equipment can severely limit your growth and profitability. The 8.5×18 Double Axle Enclosed Trailer, equipped with integrated ladder racks, is more than just a piece of equipment—it’s a comprehensive solution engineered to solve these core challenges head-on.

8.5 x 18 enclosed trailer near me

Recap the Core Benefits: Time Savings, Organization, Security, and Reliability

This trailer transforms your workflow by providing a mobile, organized, and secure command center. It saves you valuable time every single day through systematic organization and easy access to tools, particularly with the game-changing efficiency of exterior ladder racks. It provides unmatched security, protecting thousands of dollars in assets from theft and weather. Finally, its durable construction from quality materials ensures it will be a reliable partner for your business for years to come, minimizing downtime and maximizing your earning potential. By investing in this mobile workspace, you are investing in a smoother, more professional, and more profitable future for your business.
